【数码】Sheet Metal Template Doberman Sitting Project (dxf, PDF)

The Doberman Sitting involves the manufacture of steel with a thickness of 1.5 mm and a bending radius of 1 mm. The weight of the Doberman Sitting is about 14 kg. There are 56 details in total. The design documentation includes 40 pages, 38 of which are bending drawings. The instruction includes 24 pages in the order of assembly. The bend line is drawn along the cutouts in the part, in accordance with the drawing. The archive includes: dxf (38 pcs.- files separately and for a sheet 2500x1250), Drawings (40 pages), Instructions (24 pages). Overall dimensions of the sculpture (LxWxH): 673х331х1039. There is no engraving on the dxf, bending is performed along the line indicated by drop-shaped cutouts at the ends of the bending line. The project provides for nesting 2500x1250mm. If you need to create a stencil for printing in PDF format or create a DXF file with all the parts located on the sheet metal format you need, please contact me, one additional nesting I will do for free. The files you download are not intended for distribution, they are intended for you and your production. You have the right to manufacture and sell products created according to these drawings in any quantities. Thank you and good luck with your work!
